| TECHNICAL DATA Frequency band of use (± 10 dB) 50 Hz - 20 kHz SPL max at 1m 134 dB SPL (1) Nominal directionality (H° x V°) 90° x 90° (2) Nominal impedance 8 ohms Transducers Source topology Acoustic load Amplification channels and sections 1 x 12'' Neodymium coaxial ventilated - 1 x 1.4" HF motor Coaxial - APG NDB baffle Bass Reflex 2-way, mono amplified AES power (W) Maximum permissible power (W) 450 W (3) 1800 W (4) Dimensions H,W,D (mm) Weight (kg) Connectors IP 400 x 597 x 341 mm 20 kg 2 x Speakon NL4MP 43 iX12 IMMERSIVE SOUND The APG iX12 is a two-way coaxial full-range loudspeaker. The bass section is entrusted to a 12″ bass-reflex loaded driver, providing a particularly wide bass response for the size of the speaker. The high end of the spectrum is reproduced by a coaxially integrated 1.4″ compression driver, which is coaxially integrated and therefore perfectly woofer, resulting in a particularly linear phase response. linear phase response. This particular arrangement, used by APG since 1990, gives the iX12 an acoustic opening of 90° that is maintained beyond 10kHz. The APG iX12 features an anti-diffraction baffle that gives it excellent phase linearity. The result is an almost constant conical directivity. The iX12 is characterised by its high SPL/size ratio and a response in the low frequency range. ratio and a particularly wide bass response, which provides a high quality which provides highly accurate sound reproduction in both vocal and musical applications. both vocal and musical applications. The iX12 has an impedance of 8 ohm impedance. It can also be integrated into 70/100V line systems using an optional 100W or 200W transformer (option T100/T200). Ergonomic, the iX12 offers all the functions and options required for fixed indoor installation trapezoidal format, Speakon-type connectors and a stand base. base. M8 metal inserts enable it to be mounted using a range of accessories for horizontal, vertical or tilt adjustment. tilt adjustment. Reference IX12W is the white white version. The iX12 can also be customised in colour - IX12COL. STADIUM CONCERT HALLS THEATRES ACCESSORIES & OPTIONS iX12BH Mounting bracket for horizontal iX12 iX12BV Mounting bracket for vertical iX12 iX12BVAP Wall angle piece for iX12 vertical bracket T200 Line transformer 70V / 100V, 200W T100 Line transformer, 70/100 V, 100W ELECTRONICS DA8 and DA12 amplifiers APG amp |
리깅 툴 · 액세서리5
iX12 시스템용으로 제조사가 지정한 액세서리입니다. 각 항목을 누르면 도면과 자료가 있습니다.
iX12BHMounting bracket for horizontal iX12
iX12BH-OMounting bracket for horizontal iX12-O
iX12BVMounting bracket for vertical iX12
iX12BV-OMounting bracket for vertical iX12-O
iX12BVAPWall angle piece for iX12 vertical bracket기술자료14
