| TECHNICAL DATA Frequency band of use (± 10 dB) 48 Hz - 20 kHz SPL max at 1m 142 dB SPL (1) Nominal directionality (H° x V°) 100° x 10° (2) Nominal impedance 8 ohms Transducers Source topology Amplification channels and sections 2 x 10'' ND (LO) + 1 x 6,5" ND (MID) / HF 1'' (HI) Line Source 3-channel, bi-amplified Maximum number of speakers per DA8/ DA12 amplifier DA8: 4x UM210 DA12: 6x UM210 Dimensions H,W,D (mm) Weight (kg) Connectors IP 280 x797 x 533 mm 42 kg 2 x Speakon NL4MP (5) 56 UM210 The Line Array UM210 loudspeaker incorporates 3 acoustic channels and operates in bi-amplification. The LO section includes two 10" drivers, while the HI section includes a 6.5″ driver and a 1″ compression driver. This line-array loudspeaker has features adapted to the architecture of concert halls or outdoor stage configurations. On the UM210, low frequencies are reproduced by 2 x 10″ drivers positioned behind a radiation-optimising piece with a triple function: it creates a load on the woofers, increasing their efficiency, and optimises the low-frequency coupling between the various drivers that make up the loudspeaker. It also acts as a horn expander for mid and high frequencies. Its shape, calculated by BEM, ensures minimal diffraction at these frequencies. The midrange and high-frequency sections are handled by a coaxial assembly consisting of two separate drivers. A 6.5″ midrange driver at the bottom of which is installed a 1″ compression chamber motor. The electro-acoustic assembly is loaded by an innovative patent-pending phase alignment device, SIGMA, which optimises the radiation pattern and coupling between adjacent loudspeakers. FESTIVALS CONCERTS CONCERT HALLS TV PANELS ACCESSORIES & OPTIONS UMTRUSS Truss for Uniline Max (hook) UMRAIL Lightweight lifting truss and pullback UMSTACK Lightweight stacking accessory - UM121 and UC118i compatible UM210D4 Transport trolley for 4x UM210 UM210SCH4 Weatherproof cover for UM210D4 trolley ELECTRONICS DA8 and DA12 amplifiers APG amplifier with DSP fixed or touring installation series UNIRACK Universal amplification solution TOURACK Universal amplification solution |
리깅 툴 · 액세서리1
